TX7120 Intelligent Multisensor Fire Detector
The TX7110 Intelligent Heat Detector is tailored for spaces where smoke detection is unreliable — such as warehouses, kitchens, or industrial zones. Built to EN 54 Part 5 standards, this sensor monitors both fixed temperatures and rapid temperature increases (A1R class) using advanced algorithms powered by a smart microprocessor.
Its onboard processor not only detects heat anomalies but also logs event history, performs self-diagnostics, and makes autonomous fire condition decisions. The 360-degree LED indicator offers clear visual confirmation of status, making monitoring easier and faster during an emergency.
🔥 TX7120 Intelligent Multisensor Fire Detector – TNA
Delivering precision fire detection through the fusion of smoke and heat sensors, the TX7120 is the ultimate choice for versatile environments. Powered by intelligent microprocessor technology, this device combines real-time analysis, event logging, and adaptive detection to ensure fast, reliable, and false-alarm-resistant fire protection.
✅ Key Features & Benefits
🛡️ Certified & Compliant
• Fully compliant with EN 54-29:2015, EN 54-5:2017 + A1:2018, EN 54-7:2018
• LPCB and CE-CPR certified for global safety standards
🧠 Smart Microprocessor Technology
• Records up to 10 event logs
• Features algorithm mapping, drift compensation, and A/D conversion
🌡️ Dual Sensor Detection
• Combines smoke detection with rate-of-rise heat sensing
• Responds accurately to a wide range of fire scenarios
💡 360° Visual Indicator
• High-brightness LED ring visible from all angles for quick status updates
🛠️ Onsite Adjustability
• Easy parameter configuration at the installation site
• Includes remote indicator output for auxiliary signaling
🧼 Maintenance-Friendly
• Removable chamber helps prevent false alarms from dust and insects
🎨 Sleek Design
• Clean, modern look with a white glossy ABS housing
• Fits aesthetically in any residential, commercial, or industrial space
🔗 Fully Compatible System
• Designed to work seamlessly with TX7004 Analogue Intelligent Fire Alarm Panel
• Avoids addressable communication errors – built by a single manufacturer (T&A)
📝 Product Overview
The TX7120 Multisensor Detector integrates both smoke and heat detection in a single compact unit, making it ideal for applications that demand robust and sensitive fire detection. Compliant with EN 54 Part 29, this unit offers superior detection reliability across a variety of smoke patterns and temperature variations.
With its intelligent processor and real-time algorithm, the device independently analyzes signal strength, rate of temperature rise, and smoke density. It verifies the data against built-in fire scenarios to confirm threats before triggering alarms — reducing false positives while speeding up genuine response times.
The TX7120 not only logs historical data but also runs self-diagnostics, ensuring your system is always ready to perform when it matters most.
⚙️ Technical Specifications
| Specification | Details |
|---|---|
| Compliance | EN 54-29:2015, EN 54-5:2017 + A1:2018, EN 54-7:2018 |
| Certifications | LPCB / CE-CPR |
| Input Voltage | 24VDC (Range: 16V – 28V) |
| Current Consumption | Standby: 0.6 mA / Alarm: 4 mA |
| Protocol / Addressing | T&A, Range: 1 to 254 |
| Detection | Multisensor (Smoke + Heat) |
| Sensitivity | As per EN standard |
| Heat Type | Rate-of-Rise / Fixed |
| Indicator | 360° LED ring |
| Material / Finish | ABS / White Glossy |
| Dimensions | Ø 99.7 mm × 57 mm |
| Weight | 145 g (with base) / 90 g (without base) |
| Operating Temperature | –10 °C to +50 °C |
| Humidity Tolerance | 0% – 95% RH, Non-condensing |
🏢 Ideal For
✔️ Office Buildings & Apartments
✔️ Warehouses & Storage Areas
✔️ Hotels, Hospitals, and Schools
✔️ Retail Stores & Restaurants
✔️ Commercial Complexes
📌 Product Summary
-
Model: TX7120
-
Type: Multisensor Fire Detector (Smoke + Heat)
-
Brand: TNA (TANDA Development Pte. Ltd.)
-
Application: Multi-environment fire detection
-
System Compatibility: TX7004 Fire Alarm Control Panel
-
Origin: Singapore
